Automatically 3 Colors ribbon screen printing machine

  • >=1 Sets
    $32,500.00
Model Number:
SZD-303RA
Gross Power:
7kw
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 5 Sets)
Report Suspicious Activity
Overview
Quick Details
Plate Type:
Screen Printer
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
United States, Philippines, Brazil, Peru, Japan, Morocco, Chile, Kazakhstan, Tajikistan
Showroom Location:
Egypt, Canada, United States, Italy, Morocco, Colombia
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Best
Usage:
Label Printer, Bill Printer, Cloths Printer
Automatic Grade:
Automatic
Color & Page:
Single color
Voltage:
380V/50HZ 3 Phase
Dimensions(L*W*H):
3.30*1.50*1.45m
Weight:
1200KG
Certification:
CE
Warranty:
1 Year
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Key Selling Points:
High-accuracy
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Pressure vessel
Supply Ability
Supply Ability:
10 Carat/Carats per Month
Packaging & Delivery
Packaging Details
wooden case
Port
shenzhen
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated

High-Speed Stability Automatically Ribbon Screen Printing Machine





SZD-303RA Full automatically Ribbon screen printing machine//Usage and characters

Guide
  • Ribbon generally elongated sub merchandise for indicating the specified position in product features an accessory. Using loose knit nylon, polyvinyl alcohol, polyester, polypropylene, spandex, rayon and other raw materials and weaving, braiding, knitting and other technology formation.
    Monochrome screen is monochrome surfaces automatic screen printing machine for ribbon width 100mm or less, can be a single or a plurality of monochrome printing.
    High printing speed, print quality and stability. Automatic package feeding mode, saving labor intensity, pitch servo control means for printing different pitches graphic.
    Double drying tunnel drying design, greatly improving printing efficiency webbing.

Application fields
  • Various clothing trademark monochrome silk webbing;
  • Meetings, convention members listed in monochrome silk webbing;
  • With flexible features of various fabrics monochrome screen.

SZD-303RA Full automatically Ribbon screen printing machine//Parameter

Technical parameters
  • ribbon width: 10-200mm
  • Printing stroke: 600mm
  • Printing speed : 15M/Min
  • Power supply: 3 Phase 380V
  • Motor wattage: 1.5kw
  • Feeding Motor:375W;
  • IR Motor: 60W
  • Cool Motor: 5W.
  • Net weight: ≈2400kg
  • Max Frame dimension: 400×700mm.
  •  IR wattage: 2KW(1)+2KW(2)
  •  IR Length: 6000mm

Works supply
  • Power: 3 phase 380V;
  • 10M Length space for installation

Package list
  • Package dimension: 3.4*1.37*1.56m;-2pcs
  • Gross weight: 750kg.
  • 7.2789

H.S.Code

8443198000

Certificate

CE

SZD-303RA Full automatically Ribbon screen printing machine//Advantage

Function
  • That shut down for operating an ink rub net increase, which will help the color adjustment;
  • Block printing with vacuum suction function, ribbon positioning is more accurate and reliable;
  • High-speed printing, the normal per-minute speeds of up to 15M;
  • Which can print up to eight different types of ribbon;
  • Double blade design, printing, inking cleaner and reliable;
  • All-electric control, no compressed air;
  • Automatic feeding, winding tension control;
  • Smooth running smoothly, the printing stroke and speed adjustable;
  • Taiwan inverter control constant torque operation, to ensure consistent printing results;
  • Using IR infrared drying system, printing, drying synchronization is complete;



 Ribbon samples









Company Information







       Established in 2006;

        Professional engaged in fabric printing field ;

       Mainly Manufacture  Roller sublimation transfer machine, Inkjet printer, Ribbon sublimation transfer machine, Zipper sublimation transfer machine, Screen printing machine, Hot foil stamping machine Etc completely texile printing solution.







 2019. Shanghai printing exhibition, Guangzhou printing exhibition, Shenzhen printing exhibition





Our customers all over world
